Product Description
Single Output AC/DC 19V1.58A Power Supply Adapter
Single Output AC/DC 19V1.58A Power Supply Adapter Description:
JYH power
adapter, satisfy 19V1.58A, 30W output, universal 100v-240v input; DC cord is
1.2m, or you can chose 1.5m, 1.8m, 2m, 3m, standard DC jack size is 5.5*2.5mm
or 5.5*2.1mm, or you can chose other DC jack size. As for AC socket, you can
chose IEC320-C6 or C8 or C14. Please keep in mind, AC cord does not include in
the package.
Normally, we pack power adapter in the PE bag, then put into white
carton box, 50pcs/carton. But, if you want customized package, we can also
provide for you, that all depends on clients` demand.
19V1.58A dc Power adapter data:
Features:
Universal AC input/ full range
No load power consumption＜0.075W
ERP step 2 compliant
Protections: over voltage protection.over current protection.overload protection.short circuit protection
Electrical:
Dielectric withstand: 3,000VAC promary-secondary
Leakage current: 0.25mA@2Pin
Efficiency: Energy star level VI&ERP stage 2 certified
EMI conduction & radiation: Compliance to EN55022 EN55024 FCC part 15B Class B
Harmonic current: Compliance to EN61000-3-2
MTBF; 30,000 calculated hours at 25℃, by Telcordia SR-332
Safety approvals:
UL/CUL/FCC/CCC/CB/GS/CE/SAA/C-Tick/ROHS/CEC.DOE VI
Specification:
Input voltage: 100-240Vac 50/60Hz 0.5A
Output voltage: 19V 1.58A
Output loading precision: ±5%
Operating temperature: 0℃-40℃
Storage temperature: -20℃-80℃
Size: L96*W43.5*H30mm
Compatible products:
Laptop,LED lighting,Audio and video products, home appliance,Industrial automation,communications, LED Strip WS2811 WS2812 WS2801 WS2812B,etc.
Products images:
Learn more about desktop power adapter.
FAQ
1, What kind of company we are?
We are professional power supply manufacturer with high reputation in this field.
2, How we control the quality?
Aging test for 8 hours, after then we put them into the market.
3, Can we accept samples customized?
No problem for samples order, and welcome your testing before your big order.
4, What about the production capacity?
1-2 days for samples order under 10pcs, 7 days for general order under 10000pcs.
5, OEM and ODM are available?
Yes, we accept customized products.
6, Will the delivery time be long for a big order?
No, we have two special parts in production line, one for samples orders, another for big orders.
7, What is our warranty service?
For all products we sell have 2 years warranty.
